CIRS DR QC Phantom允許對DR檢測器和相關軟件進行全面的質量保證測試。
Cirs 139702 DR QC模體，Cirs 139702 DR質控模體可對月度和半年度評估進行七次質量保證評估，包括曝光線性和靈敏度，高對比度和低對比度再現性，偽像和殘留圖像檢測，圖像分辨率，準直器光束對準，測量工具精度和顯示抖動QA測試。
Cirs 139702 DR QC模體，Cirs 139702 DR質控模體尺寸為17“x 17”x 0.5“，可以快速檢查14”x 17“或17”x 17“DR系統。鉛含量已經小化，符合歐洲法規。
Cirs 139702 DR QC模體，Cirs 139702 DR質控模體帶有標準的建議測試參數，QC報告表，軟攜帶箱和48個月保修。
Cirs 139702 DR QC模體，Cirs 139702 DR質控模體特征
允許測試14“x17”（35 x 43 cm）和17“x17”（35 x 35 cm）DR系統
包括七個質量保證測試的測試對象
符合德國標準DIN 6868-58和DIN 6868-13
包含DIN Type 23 Linepair目標
大限度地減少鉛含量以符合歐洲法規
沒有活動部件
提供測試參數和QC報告表
延長12個月的保修期
| 建議的測試頻率 | |
每月測試
| 半年度測試測試
|
| Cirs139702 DR QC模體，Cirs 139702 DR質控模體產品規格 | |
| 外形尺寸 | 17“x 17”x~1 / 2“ |
| 重量 | 8磅 |
| 物料 | PMMA，銅，鋁 |
| 型號139701包括 | |
| QTY | 組件說明 |
| 1 | DR QC Phantom |
| 1 | 帶襯墊的軟包 |
| 1 | 用戶指南 |
| - | 12個月保修 |
The CIRS DR QC Phantom allows comprehensive quality assurance testing for DR Detectors and associated software.
The phantom enables seven quality assurance assessments for monthly and semi-annual evaluation, including exposure linearity and sensitivity, high and low contrast reproducibility, artifact and residual image detection, image resolution, collimator beam alignment, measurement tool accuracy, and display jitter QA testing.
The CIRS DR QC Phantom measures 17" x 17" x 0.5" and allows for quick checks on 14" x 17" or 17" x 17" DR systems. Lead content has been minimized to meet European regulations.
The phantom comes with standard suggested testing parameters, QC report forms, soft carry case and 48-month warranty.
Features
Allows testing of 14"x17" (35 x 43 cm) and 17"x17" (35 x 35 cm) DR systems
Includes test objects for seven quality assurance tests
Complies with German standards DIN 6868-58 and DIN 6868-13
Contains DIN Type 23 Linepair target
Minimized lead content to meet European regulations
No moving parts
Testing parameters and QC Report forms provided
Extended 48-month warranty
