3D單分子熒光成像系統-SAFe 360 |
SAFe 360是法國abbelight公司推出的一款基于單分子定位的顯微成像（SMLM）的新型3D單分子成像系統，它的DAISY技術整合了散光技術和超臨界角光技術，能夠大的提高定位精度，xyz三軸定位精度高達15nm，可以提供高清晰三維亞細胞結構圖像，支持同時多四色成像，可以用于細胞納米三維成像，觀測高清晰亞細胞器結構，實時研究不同的結構功能蛋白的共定位信息，在單分子水平研究分子動力學反應以及細胞間的相互作用等。
3D單分子熒光成像系統-SAFe 360
設備參數
+ 成像模式：PALM、STORM、PAINT、smFRET 、SPT
+ 光源模式：Epi、TIRF、HILO
+ 超高分辨率：15 nm的XYZ軸分辨率
+ 超大視野：200 × 200 μm2的視野
+ 一次可同時采集1.2 μm深度圖像信息
+ 大圖像深度：10 μm
+ 實時漂移矯正
+ 多四色同時成像
+ 活細胞成像模式
| 加裝 | TIRF PALM STORM SPT smFRET ...... | 兼容 | Confocal Spinning-Desk Widefield SIM STED |
Now We See......
|
|
| 3D線粒體結構 | 核孔復合物 |
|
|
| 老鼠海馬神經元 | 微管蛋白網絡 |
配套試劑
| Smartkit | Compatibledyes |
- 10 doses per box - 200 μL per dose - 30 sec prepartion - 2 months in a fridge - 2 weeks on sample | - Atto 488, WGA-AF?488 - AF?532, CF?532, Cy3b - AF?555, AF?594, CF?555, AF?568, CF?568, Cy5, MemBriteTM 568, TMR - AF?647, CF?647, AF?680, CF?680, MemBriteTM 640, Actin-stain 670, SiR647 |
發表文獻列表
[1] Radhakrishnan, A. V., et al. "Single-Protein Tracking to Study Protein Interactions During Integrin-Based Migration." The Integrin Interactome. Humana, New York, NY, (2021). 85-113.
[2] Jouchet, Pierre, et al. "Nanometric axial localization of single fluorescent molecules with modulated excitation." Nature Photonics(2021): 1-8.
[3] Pernier, Julien, et al. "Myosin 1b flattens and prunes branched actin filaments." Journal of cell science133.18 (2020).
[4] Jimenez, Angélique, Karoline Friedl, and Christophe Leterrier. "About samples, giving examples: optimized single molecule localization microscopy." Methods 174 (2020): 100-114.
[5] Mau, Adrien, et al. "Fast scanned widefield scheme provides tunable and uniform illumination for optimized SMLM on large fields of view." bioRxiv(2020).
[6] Orre, Thomas, et al. "Molecular motion and tridimensional nanoscale localization of kindlin control integrin activation in focal adhesions." bioRxiv(2020).
[7] Cabriel, Clément, et al. "Combining 3D single molecule localization strategies for reproducible bioimaging." Nature communications10.1 (2019): 1980.
[8] Woodhams, Stephen G., et al. "Cell type–specific super-resolution imaging reveals an increase in calcium-permeable AMPA receptors at spinal peptidergic terminals as an anatomical correlate of inflammatory pain." Pain160.11 (2019): 2641-2650.
[9] Belkahla, Hanen, et al. "Carbon dots, a powerful non-toxic support for bioimaging by fluorescence nanoscopy and eradication of bacteria by photothermia." Nanoscale Advances(2019).
[10] Denis, Kevin, et al. "Targeting Type IV pili as an antivirulence strategy against invasive meningococcal disease." Nature microbiology4.6 (2019): 972.
[11] Szabo, Quentin, et al. "TADs are 3D structural units of higher-order chromosome organization in Drosophila." Science advances4.2 (2018): eaar8082.
[12] Boudjemaa, Rym, et al. "Impact of bacterial membrane fatty acid composition on the failure of daptomycin to kill Staphylococcus aureus." Antimicrobial agents and chemotherapy62.7 (2018): e00023-18.
[13] Culley, Sian, et al. "Quantitative mapping and minimization of super-resolution optical imaging artifacts." Nature methods15.4 (2018): 263.
[14] Berger, Stephen L., et al. "Localized myosin II activity regulates assembly and plasticity of the axon initial segment." Neuron97.3 (2018): 555-570.
[15] Cabriel, Clément, et al. "Aberration-accounting calibration for 3D single-molecule localization microscopy." Optics letters43.2 (2018): 174-177.
[16] Bouissou, Ana?s, et al. "Podosome force generation machinery: a local balance between protrusion at the core and traction at the ring." ACS nano11.4 (2017): 4028-4040.
[17] Sellés, Julien, et al. "Nuclear pore complex plasticity during developmental process as revealed by super-resolution microscopy." Scientific reports7.1 (2017): 14732.
[18] Bourg, Nicolas, et al. "Direct optical nanoscopy with axially localized detection." Nature Photonics9.9 (2015): 587.
